Carleton xDX Collection
Cardiac Blood Test Kit
Spectral’s 'Cardiac STATus' Ponit-of-Care Test Kit
Related Entites
Identifier
2019.CU.DX.00040
Former Accession Number
5083
Date
1998 (design)
Material/Technique
Injection moulded plastic, cardboard and paper
Measurement
10.5cm (height)
box
,
15.4cm (width)
box
,
2cm (depth)
box
,
3.5cm (height)
test panel casing
,
8.8cm (width)
test panel casing
,
1.4cm (depth)
test panel casing
,
2.2cm (height)
filtration clip
,
3.5cm (width)
filtration clip
Physical Description
White box with red accents and black text containing 4 test panels in white plastic casing with colour-coded removable filtration clips in red, yellow, orange, and green, instructions and a results sticker.
Number of Components
11
Component Part Name
test panels (x4), box, filtration clip (x4), results sticker, instructions
Brand Name
Spectral
Model ID
P-4601
AAT Culture
Canadian
Style or Period
Post-1945
Work Type AAT
blood testing devices
Description
"The hand-held cardiac panel revolutionizes the medical diagnosis of heart attacks. Instead of lengthy lab work, only 15 minutes is needed for the panels to filter blood cells from a blood sample. By isolating proteins the test quickly indicates the degree and extent of the cardiac arrest.
Philip Poissant, who worked with KAN and Gerry Adamson Design, was hired as the industrial design consultant because of his skill in designing small injected moulded plastic products. The plastic casing of the cardiac panel is well crafted, simply colour-coded, light and easy to handle. Most importantly the filtration clips snap firmly into place and can be removed easily.
The filtering system is patented and is exported to the USA, Europe, and Asia.
Awards: Gold, Design Effectiveness Award, 1998"
Philip Poissant, who worked with KAN and Gerry Adamson Design, was hired as the industrial design consultant because of his skill in designing small injected moulded plastic products. The plastic casing of the cardiac panel is well crafted, simply colour-coded, light and easy to handle. Most importantly the filtration clips snap firmly into place and can be removed easily.
The filtering system is patented and is exported to the USA, Europe, and Asia.
Awards: Gold, Design Effectiveness Award, 1998"
Description Source
DX Collection Registration Records FileMaker PDF
